70718 - MARATHON PUMP

Revision no.: 2 | Date: 15-09-2023

MARATHON PUMP

Piezas del despiece (kits o unitarios)

POS. CÓDIGO DESCRIPCIÓN
1 4405011101 KEY FOR PREFILTER NUT
    • 2 4405010770 THREADED LID COLLAR
    • 3 4405010771 PRE-FILTER COVER
    • 4 4405010772 O' RING D 151,7X6,99
    • 5 4405011103 PRE-FILTER BASKET
    • 6 4405010773 SOCKET O'RING
    • 7 4405010775 UNION FITTINGS D 63
    • 8 4405010776 PUMP HOUSING
    • 9 4405010090 DRAIN PLUG
    • 10 4405011107 PUMP BASE
    • 11 4405010778 PUMP BASE FITTINGS 1,5 HP - 3 HP
    12 4405010161 O' RING D. 56,7X3,5
    • 13 4405011134 DIFFUSER 2-3 HP.
    • 14 4405010779 IMPELLER COVER
    • 15 4405011139 IMPELLER 1,5 HP. II 50 HZ
    • 16 4405010780 DEFLECTOR WASHER
    17 4405011112 MECHANICAL SEAL D-15
    • 18 4405010781 MOTOR CLAMP GASKET
    • 19 4405010782 FLANGE MECANICAL SEAL
    20 4405010783 MOTOR SCREW
    21 4405010785 MOTOR CLAMP (1,5 - 3 HP)
    22 4405010787 DEFLECTOR WASHER C.80 1,5-3 HP
    23 4405010847 BEARINGS ASSEMBLY
    24 4405011131 REAR MOTOR COVER (1,5-3 HP II)
    • 25 4405010851 FAN COVER + FAN
    • 26 4405011118 FRONT MOTOR COVER (1,5 - 3 HP II)
    • 27 4405011211 CONDENSER 20 UF (3/4 - 1 HP LL)
    • 28 4405011213 TERMINAL BOX ASSEMBLY II
